Accessories
Accessories for ADRO-V55100,X55100 and USB-Scope Serie
Probe 3,9 mm
Diameter 3,9mm
DOF (Depth of Field) 1 -2 cm
| Article No | Description |
| 391010 | Probe 3,9x1000mm flexible |
| 391020 | Probe 3,9x2000mm flexible |
| 391030 | Probe 3,9x3000mm flexible |
Probe 4,3 mm
Diameter 4,30 mm
DOF (Depth of Field) 1 -2 cm
| Article No | Description |
| 431010 | Probe 4,3x1000mm flexible |
| 431020 | Probe 4,3x2000mm flexible |
| 431030 | Probe 4,3x3000mm flexible |
| 431050 | Probe 4,3x5000mm flexible |
| 431100 | Probe 4,3x10000mm flexible |
Probe 5,5 mm
Diameter 5,50 mm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
Light 6 LED
DOF (Depth of Field) 1 cm
| Article No | Description |
| 551010 | Probe 5,5x1000mm flexible |
| 551020 | Probe 5,5x2000mm flexible |
| 551030 | Probe 5,5x3000mm flexible |
| 551050 | Probe 5,5x5000mm flexible |
| 551100 | Probe 5,5x10000mm flexible |
| 551200 | Probe 5,5x20000mm flexible |
| 551300 | Probe 5,5x30000mm flexible |
| 551013 | Probe 5,5x1000mm flexible 90° fix Side view Camera |
| 551023 | Probe 5,5x2000mm flexible 90° fix Side view Camera |
| 551033 | Probe 5,5x3000mm flexible 90° fix Side view Camera |
| 551010M | Probe 5,5x1000mm metal braided |
| 551020M | Probe 5,5x2000mm metal braided |
Probe 5,8 mm
Diameter 5,58 mm
DOF (Depth of Field) 4 -5 cm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lieght 6 LED
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
| Article No | Description |
| 582010 | Probe 5,8x1000mm semi rigid |
| 582020 | Probe 5,8x2000mm semi rigid |
| 582030 | Probe 5,8x3000mm semi rigid |
Probe 8 mm
Diameter 8,00 mm
DOF (Depth of Field) 2 cm flexible Cable 8cm semi rigid Cable
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
| Article No | Description |
| 801010 | Probe 8,0,x1000mm flexible |
| 801020 | Probe 8,0,x2000mm flexible |
| 801030 | Probe 8,0,x3000mm flexible |
| 802010 | Probe 8,0,x1000mm semi rigid |
| 802020 | Probe 8,0,x1000mm semi rigid |
Probe25 mm
Diameter 20,00 mm
DOF (Depth of Field) 14 cm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
| Article No | Description |
| 252030 | Probe 25x3000mm semi rigid |
Articulation Tube 5,5 and 8 mm
Diameter 5,5 mm an 8mm
DOF (Depth of Field) 1,5 cm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
6 LED
Mounted on the Video endoscope
| Article No | Description |
| A551010 | 2-Way Articulation Probe 5,5x1000mm felxible |
| A551020 | 2-Way Articulation Probe 5,5x2000mm flexible |
| A551030 | 2-Way Articulation Probe 5,5x3000mm flexible |
| A801010 | 2-Way Articulation Probe 8x1000mm felxible |
| A801020 | 2-Way Articulation Probe 8x2000mm felxible |
Rigid Articulation
Diameter 5,5
DOF (Depth of Field) 1,5 cm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
6 LED
Mounted on the Video endoscope
5,5x300mm
Articel Nr : RA55301
Rigid Scope 6,0mm
Diameter 6 mm
DOF (Depth of Field) 2 cm
Resolution (Dynamic Static) : 720 x 480 pixels, Video 720 x 480 pixels (30 fps),
Lens: 300,000 pixels, 60 fps@AVGA, CMOS
Mounted on the Video endoscope
360° Articulation
| Article No | Description |
| R60301 | Rigid Scope 6x300mm (12") |
| R60302 | Rigid Scope 6x450mm (17") |
2,7mm and 5mm Rigid Scope
Adronic 2.7mm and 5mm Rigid Video Scope, unique design for small diameter inspection purpose, allows Rigid Scope
images picture transfer to a portable V55 video system. Users enable to see image picture from a 3.5” LCD screen, support
snapshot (JPG) and Video recording (MP4).
 |
Resolution (pixies): 1028 x 1024 |
|
|
Rigid Scope Out- Dimension: 2.7mm or 5mm |
|
|
Rigid Scope length: 205mm |
|
|
Focal Format: 1/2” |
|
|
Focal Mount: C/CS |
|
|
Focal Dimension: ∮50 x L42 |
|
|
3.5” LCD display |
|
|
Video recording (MPEG4) |
|
|
Snapshot (JPEG format) |
|
|
Replay video and image |
|
|
include a 2GB SD card for storing video, image and editing on a PC. |
|
|
With 16 operation languages software |
|
|
Support AV out (PAL/NTSC selectable) |
|
|
Portable battery design allow user to changing battery at any time. |
|
|
With USB port (1.1/2.0) allow user transfer data to PC |
|
|
Illumination LED light adjustable |
| Article No | Description |
| R272CD3527 | 2,7mm Rigid Scope |
| R502CD3527 | 5mm Rigid Scope |
Mirrors/Magnet/Guide Ball
| Article No | Description |
| S40010 | Mirror 35-70° 4mm |
| S40020 | Mirror 45-90° 4mm |
| S40030 | Mirror 55-120° 4mm |
| S40040 | Guide Ball 4mm |
More Mirrors etc. You will find in our Calalog: click here
Feature
